This structure allows for images to be displayed on both the front and back sides, and it can form an
independent structure using angle brackets as connectors.
Where LC-DR-120A fits
In a 120 mm build, LC-DR-120A leaves room for a diffuser and an LED row without making the box look heavy from the street. Either face can be swapped independently, so a seasonal change never touches the structure behind it.
Build, finish and compatibility
Extruded in 6063-T5 aluminum; corners close with angle brackets, free-standing (can stand securely with connectors), and the profile can be finished in silver, black, white or a custom colour to match a booth scheme. The cavity takes a standard LED row plus diffuser, so brightness is specified per square metre rather than guessed at the frame stage.
Cutting, packing and lead time
Bars come at 3.5 m, 5 m or 6 m (custom lengths on request) and are cut to your cut list; anodised faces are sleeved individually before kraft wrapping so both visible sides arrive unmarked. Stock sections quote in 24 hours and ship in 3–5 days; powder-coated or custom-cut frames take 15–25 days, with a sample corner assembly available first.
Specification snapshot
LC-DR-120A is a double-sided frame, at 120 mm depth, 2.028 kg per metre, in 6063-T5 aluminum; bars come at 3.5 m, 5 m or 6 m (custom lengths on request), packed in non-woven fabric/kraft paper.
Q: Can LC-DR-120A be lit?
A: Yes — the 120 mm cavity takes a standard LED row and diffuser, and strip pitch and driver size are quoted against the panel area.
Q: What lengths and colours can I order?
A: 3.5 m, 5 m or 6 m (custom lengths on request), cut to your cut list; colours are silver, black, white or a custom colour.
Q: How fast is a quote and a sample?
A: Quote within 24 hours of a panel drawing; stock ships in 3–5 days, custom coating and cut lists 15–25 days, and a sample corner assembly can be sent first.
